Mono-metal piston with windows · Vocabulario en imágenes · 11 palabras
Aprende 11 palabras de «Mono-metal piston with windows» con imágenes etiquetadas y audio de hablantes nativos: mono-metal piston with windows, piston ring, locking pin, ring end gap, locking-pin recess, intermediate land. Incluye pronunciación, etiquetas bilingües y un PDF A4 imprimible gratis.
Palabras etiquetadas en esta imagen（11）
1
mono-metal piston with windows
2
piston ring
3
locking pin
4
ring end gap
5
locking-pin recess
6
intermediate land
7
piston window
8
inner circlip
9
center circlip
10
piston
11
piston skirt
