Exhaust control with control drum · Vocabulario en imágenes · 8 palabras
Aprende 8 palabras de «Exhaust control with control drum» con imágenes etiquetadas y audio de hablantes nativos: exhaust control drum, exhaust-edge adjustment, adjustment range, segment cutout, control drum, long timing. Incluye pronunciación, etiquetas bilingües y un PDF A4 imprimible gratis.
Palabras etiquetadas en esta imagen（8）
1
exhaust control drum
2
exhaust-edge adjustment
3
adjustment range
4
segment cutout
5
control drum
6
long timing
7
short timing
8
exhaust
