Reverse scavenging · Vocabulario en imágenes · 8 palabras
Aprende 8 palabras de «Reverse scavenging» con imágenes etiquetadas y audio de hablantes nativos: reverse scavenging, exhaust port, intake port, transfer port, piston window, fresh charge. Incluye pronunciación, etiquetas bilingües y un PDF A4 imprimible gratis.
Palabras etiquetadas en esta imagen（8）
1
reverse scavenging
2
exhaust port
3
intake port
4
transfer port
5
piston window
6
fresh charge
7
exhaust gas
8
schematic
