Diaphragm control · 図解英単語 · 9 語
「Diaphragm control」の9語をラベル付きイラストとネイティブ音声で学習：diaphragm-controlled timing, diaphragm petal, diaphragm stopper, gasket, housing flange, diaphragm valve。発音・バイリンガル表記・無料で印刷できるA4 PDF付き。
このイラストの点読単語（9）
1
diaphragm-controlled timing
2
diaphragm petal
3
diaphragm stopper
4
gasket
5
housing flange
6
diaphragm valve
7
intake
8
scavenging
9
exhaust
