Multi-port reverse scavenging (loop scavenging) · 図解英単語 · 8 語
「Multi-port reverse scavenging (loop scavenging)」の8語をラベル付きイラストとネイティブ音声で学習：multi-port loop scavenging, exhaust gas core, main transfer port, auxiliary transfer port, intake port, exhaust port。発音・バイリンガル表記・無料で印刷できるA4 PDF付き。
このイラストの点読単語（8）
1
multi-port loop scavenging
2
exhaust gas core
3
main transfer port
4
auxiliary transfer port
5
intake port
6
exhaust port
7
loop formation
8
fresh charge
